LATTICE-03

General Features

Frame Color

LATTICE-03 (10W / 15W)

The LATTICE-03 is a compact magnetic track light designed for premium accent and display lighting. With dual power options of 10W and 15W, a fixed 32° beam angle, and high CRI 90+ color rendering, it delivers precise illumination ideal for retail displays, galleries, and hospitality environments. Operating on a DC48V magnetic track system, this luminaire offers clean, minimalist aesthetics with flexible positioning along the track. Available in 3000K and 4000K color temperatures, the LATTICE-03 provides warm to neutral white light tailored to your space.

Specs

Features

• Power options: 10W / 15W
• DC48V input voltage for safe low-voltage operation
• 32° beam angle for precise accent and spot lighting
• CRI 90+ for accurate and vibrant color rendering
• Available in 3000K (warm white) and 4000K (neutral white)
• Compatible with 20mm magnetic track systems
• Sleek, compact design for seamless integration
• Suitable for retail, hospitality, museum, and gallery applications

Specsheet

Model	Power	Voltage	Beam Optics	CRI	CCT
LATTICE-03	10W	DC48V	32°	90+	3000K / 4000K
LATTICE-03	15W	DC48V	32°	90+	3000K / 4000K
